Magnetismus 2

Demo

Register now and get the Magnetismus 2 for 14 days without any commitment.

  • You register.
  • We send you the device to your studio by appointment.
  • You try it out for 14 days.
  • Then you decide if you want to keep it.
  • If not, you can return it without any ifs or buts.
(For demos outside of Germany we will either forward you to one of our international partners or send you a demo with a security deposit.)

Description

Magnetismus 2
Transient Shaper

The Magnetimus 2 is a good candidate to be Tegeler’s most versatile device: it was first conceived, among other things, for processing transient-rich signals, such as drums, synthesizers, and acoustic guitars. It combines a modern, flexible VCA compressor with a downstream transient shaper. The result is a thick, rich sound, that helps integrate tracks better into the mix, similar to a tape recording.

Transient shaper

The transient shaper does not simply change the level of the transients, but, much like a tape machine, it rounds out the transients. The three different Flux Modes (Eisen, Kobalt, and Nickel) will run your signal through different transformers that emulate analogically the saturation of tapes made respectively of iron, cobalt, and nickel.

VCA compressor

In its first stage, you will find a powerful VCA compressor, with Threshold, Timing, Ratio, and Make-Up Gain controls. As its brother Creme does, the Magnetismus 2 can compress any stereo signal to ensure that the peaks are attenuated without compromising the dynamic range of your mix. More than anything, it can - and should - be used to “glue” mixes together.

Modi

The way the Flux Mode does that is by changing the time window for the processed transients slightly, causing the transient to be rounded more or less depending on the width of the transients. With the Intensity knob, you can control how much the transient shaping will change the original signal, enabling you to sculpt your envelope as finely as possible.

Transformer stage

The additional transformer at the output adds another bit of density, which will bring your modified up as much as you want, allowing that final touch of punch that a mix sometimes needs.

Using more extreme settings, the Magnetismus 2 can also be very helpful in creative sound design, by crushing or destructing audio signals; it can be used as a very straightforward drum smasher, for example.

Signal flow

Since the VCA compressor can also be used separately, the Magnetimus 2 is also suitable for processing sum signals, as a bus compressor, or even as a mastering compressor. Whatever sonic painting you want to create, the Magnetismus 2 is your perfect canvas.

Magnetismus 2 block diagram Signal flow chart

Photos

Videos

Magnetismus 2 Review by Marlow Digs

Magnetismus 2 + TR-808

Magnetismus 2 Review by Euge Valovirta

(Auf Deutsch) Druckvoll mischen mit dem Magnetismus 2

Magnetismus 2 Review by White Sea Studio

(In italiano) Magnetismus 2 Review

Magnetismus 2 Review by Glenn Fricker

Soothe 2 vs Gullfoss vs Intensity by Zynaptiq, along with Magnetismus 2

Grooves mit dem Magnetismus 2 bearbeiten - AG-KW Techno

Magnetismus 2 acoustic drums (no talking)

Magnetismus 2 electronic percussion (no talking)

Magnetismus 2 synthesizer Moog Minitaur (no talking)

Magnetismus 2 Elektron Analog Rytm (no talking)

Magnetismus 2 acoustic guitar (no talking)

Features

Features

  • Stereo Unit
  • Input: Balanced XLR
  • Output: Transformer Balanced XLR
  • VCA Compressor
  • Adjustable threshold and ratio
  • Wide range of adjustable timing
  • LED gain reduction meter
  • Adjustable level and intensity of transient processing
  • Illuminated VU meter for working point control
  • Adjustable output level
  • Stepped Potentiometers
  • Bypass Switch
  • Internal power supply
  • Height: 88,1mm (2HE), width: 483mm, depth: 250mm

Specifications

  • Frequency Response: 20Hz - 22kHz
  • Maximum Input Level: +20 dBu
  • Input Impedance: ≥ 2.4kΩ
  • Output Impedance: < 600 Ω
  • Maximum Output Level: +24 dBu
  • Dynamic Range: ≥ 95 dB
  • Voltage: 110- 240 V~/50-60 Hz
  • Fuse: 500mA slow-blow
  • Maximum Power Consumption: < 25 W
  • Dimensions: 2 U, H:88.1 mm, W:483 mm, D:250 mm

News

Digital Recall Sheets
  • 17.05.2017
  • News
  • Konnektor
  • Creme
  • Mag2
  • TSM
  • VTC
  • VTRC
  • EQP

It's easier than ever to keep your analog outboard gear configured right. The Schwerkraftmaschine and Konnektor from Tegeler Audio Manufaktur already offer flawless total recall...

Gordon Raphael about the work with the Tegeler Audio Manufaktur products
  • 15.04.2015
  • Story
  • VTRC
  • Mag2
  • EQP-1
  • VTC

Gordon Raphael is a record producer and musician from Seattle, who is currently living in Berlin. He is most widely known for his work with The Strokes, whom he met while attending...

Side-Chain - what it is and what it isn’t, Part 3
  • 01.10.2013
  • Story
  • Basics
  • Compression
  • VTRC
  • VTC
  • Mag2
  • Creme

Die Baugruppen, mit welchen die Audiosignalverstärkung verändert wird, geben den Kompressoren normalerweise ihren Namen. Man unterscheidet hauptsächlich: Kompressoren nach dem Va...

Magnetismus 2 live - Jazz with the Portico Quartet at Séance Berlin
  • 22.04.2013
  • Story
  • Mag2

In the context of the concert series Séance Berlin, the Portico Quartet appeared with an interesting fusion of jazz and electronics. The Magnetimus 2 was used on the drum bus for t...

Magnetismus 2 now separate side chain input
  • 10.02.2012
  • Mag2

All new Magnetismus 2 are now equipped with a separate side chain input. This extension will make the built-in VCA compressor even more flexible. Old units Magnetismus 2 can be u...

Testbericht über Magnetismus2 bei Amazona.de
  • 11.08.2008
  • Testbericht
  • Mag2

Das Onlinemagazin Amazona.de hat unseren Magnetismus2 getestet. Amazona.de 11.08.2008 Hagen Fin schrieb: …Der Tegeler Magnetismus 2 ist ein hochwertiges, sehr gut verarbeitetes ana...

Reviews

Amazona.de
Amazona.de
  • 2008-08
  • Hagen Fin
...The Tegel Magnetism 2 is a high-quality, very well-made analog studio device with an excellent sounding compressor and transient processing that can conjure up a certain vintage flair in the audio material...

...However, the compressor is more than usable for almost all common things and works very effectively...

Order

Availability
in stock
Art. No. 2.727-00
Preis 1.699,00 €
Price incl. 19% VAT, plus shipping)
We ship worldwide.

Suitable cable

Cable XLR female-TRS 2m

Availability
in stock
Preis 9,99 €
Price incl. 19% VAT, plus shipping

Cable XLR male-TRS 2m

Availability
in stock
Preis 9,99 €
Price incl. 19% VAT, plus shipping

Cable XLR male-XLR female 2m

Availability
in stock
Preis 9,99 €
Price incl. 19% VAT, plus shipping

End your inner battle between digital and analog.
